Pressure die cast aluminium housing, powder coated with weather proof gasket ensuring IP66.
Heat resistant toughened glass.
High Efficiency Street Lighting Lenses.
Surge protection Inbuilt 4KV, optional 10KV with external Surge Protection device
Constant Current LED Driver with » 85% efficacy.
THD < 10% and Power factor * 0.95.
LED Colour - W.W., N.W., C.W. (2700K-6500K)
| Model No | Power | Dimension (A x B x C) mm | Input Voltage | Frequency | Power Factor | Luminous | Price |
|---|---|---|---|---|---|---|---|
| GKM-FD-M-18 | 18 Watt | 195 X 140 X 55 | 2500.00 | ||||
| GKM-FD-M-40 | 40 Watt | 295 X 225 X 60 | 4500.00 | ||||
| GKM-FD-M-50 | 50 Watt | 295 X 225 X 60 | 5500.00 | ||||
| GKM-FD-M-60 | 60 Watt | 295 X 225 X 60 | 6100.00 | ||||
| GKM-FD-M-72 | 72 Watt | 295 X 225 X 60 | AC 120~270V | 50 Hz± 5% | > 0.95 | >120 Lum/W | 6700.00 |
| GKM-FD-M-90 | 90 Watt | 350 X 275 X 65 | 9000.00 | ||||
| GKM-FD-M-100 | 100 Watt | 350 X 275 X 65 | 9400.00 | ||||
| GKM-FD-M-120 | 120 Watt | 350 X 275 X 65 | 10400.00 | ||||
| GKM-FD-M-150 | 150 Watt | 350 X 275 X 65 | 10800.00 |
H-28, Site C, Surajpur Industrial Area, Greater Noida, Uttar Pradesh-201306
All our products are manufactured as per IEC, ISI, BIS Standards and approved by the Ministry Of New & Renewable Energy, Government Of India. Our manufacturing plant is also accredited with ISO 9001 for manufacturing & marketing of Solar Power products.
